LED Controller 2-in-1 Monochrome + CCT 2.4GHz RF

LED-00695

Dimmable Yes

New product

The LED Controller 2-in-1 Monochrome + CCT 2.4GHz RF enables seamless wireless control of LED lighting including brightness and color temperature adjustments. It supports Mi-Light/MiBoxer remotes with a 30 m range and operates efficiently within -10°C to 40°C.

242 Items

Order now and receive it The day after tomorrow

21,18 € tax incl.

Métodos de pago

More info

2-in-1 LED controller (2.4GHz) for monochrome + CCT to control your LED lighting using Mi-Light/MiBoxer remote controls. Enjoy quick, tool-free installation and reliable remote control with a 30 m range. Adjust brightness and color temperature (CCT) to set up LED lighting scenes comfortably and simply.

Installation and Compatibility

This LED controller is designed for easy installation without requiring additional tools, making it accessible for quick setup. It is compatible with Mi-Light and MiBoxer remote controls, facilitating versatile control options for various LED lighting configurations including monochrome and tunable white (CCT) LED setups.

Performance and Environmental Conditions

The device operates reliably in ambient temperatures ranging from -10°C to 40°C, ensuring stable performance in typical indoor environments. The 2.4GHz RF wireless technology allows for a stable connection and control range of up to 30 meters, providing flexibility in placement and convenient remote operation.

Frequently Asked Questions

What types of LED lights can be controlled with this device?

It controls both monochrome LEDs and tunable white (CCT) LED lights, allowing control of brightness and color temperature.

Which remote controls are compatible?

The LED controller is compatible with Mi-Light and MiBoxer remote controllers operating at 2.4GHz frequency.

What is the maximum operating temperature for this controller?

The controller is rated to operate within temperatures from -10°C up to 40°C.

How far can the remote control operate from the controller?

The wireless 2.4GHz connection supports control up to 30 meters away, depending on environmental conditions.

View technical specifications Hide technical specifications
Rated Voltage DC 12 -24V
Operating Frequency (Hz) 2.4GHz
Temperature Range (ºC) -10ºC ~ +40ºC
Light Temperature COLOR SELECTABLE: 2700K -3000K-4000K-6000K
Range (m) 30m
Dimmable Yes

LED strips and flexible neon for linear and decorative lighting

LED strips and flexible neon make it possible to create continuous lines of light, illuminate furniture and highlight architectural features with a discreet and adaptable installation. They are used in homes, shops, restaurants, hotels, window displays, offices, terraces, signs and decorative projects.

At DomiLED you will find solutions with different power ratings, operating voltages, colour temperatures, brightness levels and IP protection ratings. Before choosing a product, define the required effect, installation length, mounting location and whether you need white, dimmable or colour-changing light.

Differences between LED strips and flexible neon

LED strip lights contain small diodes mounted on a flexible circuit. They are suitable for installation under cabinets, on shelves, around ceilings, inside display cases, along stairs, in aluminium profiles and in areas where the light source can remain concealed.

Flexible LED neon uses a diffusing cover that hides the individual LED points and produces a more uniform line of light. It is suitable for outlines, shapes, signs, façades, decorative walls and applications where the illuminated line remains visible.

How to choose an LED strip

Power consumption per metre and luminous output determine how much electricity the strip uses and how much light it produces. A moderate output may be sufficient for ambient lighting, while worktops, shop displays and working areas usually require a brighter strip.

The operating voltage must also be checked. Low-voltage LED strips require a correctly sized compatible power supply. Calculate the required power according to the consumption per metre and total installation length, including a safety margin so the power supply does not continuously operate at its maximum capacity.

Warm, neutral, cool white, RGB and RGBW

Warm white strips create a comfortable atmosphere in living rooms, bedrooms, restaurants and hotels. Neutral white provides balanced illumination for kitchens, shops and working areas, while cool white creates a brighter and more technical appearance.

RGB LED strips allow different colours to be selected through a controller. RGBW strips also include a dedicated white-light channel, providing more practical white illumination in addition to coloured effects. A compatible controller is required to adjust brightness or change colours.

Installation, cutting and IP protection

LED strips and flexible neon should only be cut at the points indicated by the manufacturer. Before installation, check the length of each section, connection type and required power supply. Long runs may need to be powered from more than one point to prevent a visible loss of brightness.

An aluminium profile for LED strips improves the finish, helps dissipate heat and protects the installation. For bathrooms, terraces, façades and areas exposed to moisture, choose a suitable IP rating and ensure that all connections and ends are properly sealed.

Explore our selection of LED strip lights, flexible LED neon, power supplies, controllers and accessories and find a complete solution for efficient linear and decorative lighting.
